How does an osmosis water purification system remove dissolved solids?

To get clean, safe water for many industrial and business uses, an osmosis water purification system is a very good way to get rid of dissolved solids in water. A semi-permeable screen is used in this advanced technology to separate water molecules from pollutants. Most of the dissolved solids are gone after this. To beat the natural osmotic pressure during the process, pressure is used. Larger particles, ions, and other impurities are pushed behind the membrane as water molecules pass through. In the end, this makes clean water that can be used for many things, from making food and drinks to making medicines and electronics.

Mechanism of solute rejection by RO membranes

The heart of an osmosis water purification system lies in its reverse osmosis (RO) membranes. These sophisticated membranes are designed with microscopic pores that allow water molecules to pass through while blocking larger particles and dissolved solids. The rejection mechanism involves several factors:

Size exclusion

The most straightforward aspect of solute rejection is size exclusion. Most RO membranes have holes that are between 0.1 and 1 nanometer in size, which is much smaller than most dissolved solids and pathogens. Larger molecules and ions can't get through the membrane because of this physical barrier.

Charge repulsion

It's helpful that many RO membranes are negatively charged because they push away negatively charged ions that are found in water, like chloride, sulfate, and nitrate. The membrane can reject dissolved solids better because of this charge repulsion, even if the solids are smaller than the membrane's pores.

Diffusion control

The rate at which water molecules pass through the membrane is much higher than that of dissolved solids. This difference in diffusion rates contributes to the overall efficiency of the solute rejection process, allowing for high-quality permeate production.

What role does applied pressure play in solute removal?

Applied pressure is a vital factor in the operation of an osmosis water purification system. It serves several important functions in the solute removal process:

Overcoming osmotic pressure

Naturally, water tends to move from an area of low solute concentration to an area of high solute concentration, a process known as osmosis. In a reverse osmosis plant, applied pressure is used to overcome this natural osmotic pressure, forcing water in the opposite way through the semi-permeable membrane.

Enhancing flow rate

The flux rate is the amount of water that moves through the membrane per unit area per unit time. It is directly related to the pressure that is being used. Higher pressure generally results in a higher flux rate, increasing the system's overall efficiency and productivity.

Improving rejection efficiency

As the applied pressure increases, the rejection efficiency of the membrane also improves. This is because higher pressure helps to maintain the integrity of the membrane structure and enhances its ability to block dissolved solids.

Optimizing energy consumption

While higher pressure can improve efficiency, it also increases energy consumption. Modern BWRO plant designs try to optimize the applied pressure to achieve the best balance between solute removal efficiency and energy usage.

Membrane materials: TFC, CA and selection factors

The choice of membrane material plays a major role in the performance and efficiency of an osmosis water purification system. Two primary types of membrane materials are widely used in RO systems:

Thin Film Composite (TFC) membranes

TFC membranes are the most widely used in modern RO systems, including BWRO plants, due to their better performance characteristics:

• High salt rejection rates (up to 99.5%)
• Excellent chemical stability
• Resistance to bacterial fouling
• A wide range of pH levels
• Higher rates of flow than CA membranes

TFC membranes are made up of several layers, such as a polyester support layer, a microporous polysulfone layer, and an ultra-thin polyamide barrier layer. This complex structure makes it possible for performance and durability to be at their best.

Cellulose Acetate (CA) membranes

While less popular in modern systems, CA membranes still find applications in specific scenarios: Higher chlorine endurance compared to TFC membranes

Cost less

Smoother surface, possibly reducing fouling in some applications
However, CA membranes tend to reject fewer salts and are more easily broken down by water, which limits their pH range and shortens their total life.

Things that affect choice

The selectivity of RO membranes depends on different factors:

• Pore size and distribution
• Membrane surface charge
• Balance of hydrophilicity and hydrophobicity
• Thickness of membrane
• Operating factors (pressure, temperature, pH)

These things affect how well the membrane can reject certain ions and molecules. This means that RO systems can be changed to fit different water treatment needs.

Conclusion

Filtration systems that use osmosis, especially those that use reverse osmosis, are strong and good at getting rid of solids that are mixed with water. Using the ideas of size exclusion, charge repulsion, and controlled diffusion, these systems can make good water that can be used in many business and industrial settings. The combination of cutting-edge membrane materials, carefully chosen working conditions, and well-thought-out system design makes it possible to remove solutes very well while keeping energy costs low and operational expenses low.

As the standards for water quality get stricter in more and more businesses, osmosis water purification systems become more and more important. These systems provide a flexible and dependable way to deal with water treatment problems, from making sure drinking water is clean to meeting the strict demands of making pharmaceuticals and semiconductors.

FAQ

Q1: What is the average lifespan of RO membranes in an osmosis water purification system?

A: The lifespan of RO membranes depends on things like the quality of the water, how well the system is maintained, and how it is used. Good membranes in systems that are well taken care of can last between 3 and 5 years on average. Some membranes may last up to 7–10 years, though, if they are well taken care of and used in the best circumstances.

Q2: How does weather affect the performance of a reverse osmosis plant?

A: Temperature has a big effect on how well a RO system works. Generally, higher temperatures increase water flux through the membrane, possibly improving system productivity. But high temperatures can also make it less effective to get rid of salt and may speed up membrane breakdown. Most RO systems are made to work best between 20°C and 30°C (68°F and 86°F), but they can be adjusted to work in temperatures higher or lower than these.

Q3: Can a BWRO plant get rid of all kinds of solids that melt in water?

A: BWRO plants are very good at getting rid of many types of dissolved solids, but they might not get rid of all pollution. Most of the time, the refusal rate for dissolved solids is between 95 and 99.5%. There's a chance that some very small molecules or particles with no charge will get through the barrier. For uses that need very high purity, extra steps of treatment like electrodeionization (EDI) or mixed-bed ion exchange may be needed after the RO process.

Quality Osmosis Systems for Cleaning Water | Morui

We at Guangdong Morui Environmental Technology Co., Ltd. know how important it is for your business to have water purification systems that work well and are reliable. Our cutting-edge osmosis water purification systems are made to meet the needs of a wide range of industries, from those that make food and drinks to those that make drugs and electronics.

Because we are committed to innovation and have a lot of experience with water treatment technologies, we can offer custom solutions that work very well and are a good value. Our team of professional engineers and technicians works closely with you to create and set up the best water purification system for your needs.

Don't let problems with the water quality stop your work. Get in touch with us right away at benson@guangdongmorui.com to find out more about our advanced osmosis water purification systems and how we can help you make your water treatment processes better. Let Guangdong Morui be your reliable partner in improving the quality of your water and the efficiency of your operations.

References

1. It was written by Greenlee, L. F., Lawler, D. F., Freeman, B. D., Marrot, B., and Moulin, P. Sources of water, technology, and problems in reverse osmosis desalination today. Research in Water, 43(9), 2317–2348.

2. They are Lee, K. P., Arnot, T. C., and Mattia, D. (2011). An analysis of reverse osmosis membrane materials used for desalination, including progress made so far and what could happen in the future. 370(1), 1–22 in the Journal of Membrane Science.

3. Malaeb, L., & Ayoub, G. M. (2011). Reverse osmosis technology for water treatment: State of the art review. Desalination, 267(1), 1–8.

4. The authors are Fritzmann, C., Löwenberg, J., Wintgens, T., and Melin, T. (2007). State-of-the-art of reverse osmosis desalination. Desalination, 216(1-3), 1-76.

5. Elimelech, M., & Phillip, W. A. (2011). The future of seawater desalination: Energy, technology, and the environment. Science, 333(6043), 712-717.

6. Ghaffour, N., Missimer, T. M., & Amy, G. L. (2013). Technical review and evaluation of the economics of water desalination: Current and future challenges for better water supply sustainability. Desalination, 309, 197-207.
